NoIR Camera & NIR: Auto White Balance Fixes

Hey guys! Ever found yourself wrestling with weird colors in your Raspberry Pi camera projects, especially when venturing into the realm of NIR (Near-Infrared) imaging? You're not alone! This article dives deep into the nitty-gritty of auto white balancing (AWB) on the Raspberry Pi NoIR V2.1 camera, focusing on how it interacts with NIR LEDs and how to achieve the perfect color balance in your projects. We'll explore the challenges, the solutions, and everything in between, making your NIR imaging journey a whole lot smoother.

The Curious Case of the NoIR Camera and White Balance

So, you've got your Raspberry Pi, your NoIR V2.1 camera, and a bunch of cool 940nm NIR LEDs. You fire up your setup, eager to capture some invisible light magic, but the colors are... off. Way off. Purples where there should be greens, reds where there should be blues – it's a color party gone wild! What's happening?

The culprit is often the auto white balance (AWB) algorithm built into the camera. AWB is a clever piece of software that tries to make the colors in your images look natural, as if captured under standard daylight conditions. It does this by analyzing the scene and adjusting the red, green, and blue channels to compensate for different lighting conditions. Think of it as the camera's attempt to neutralize the color cast introduced by various light sources, whether it's the warm glow of incandescent bulbs or the cool hue of fluorescent lights.

However, here's the catch: AWB is designed primarily for the visible spectrum, the range of light that our eyes can see. When you introduce NIR light, which is invisible to the human eye but very much detectable by the NoIR camera, the AWB system gets thrown for a loop. NIR light interacts differently with objects than visible light, and the camera's sensors pick up this difference. The AWB algorithm, blinded by the invisible, struggles to interpret the scene correctly, resulting in those funky, unexpected colors. The NoIR camera, lacking the infrared (IR) filter of the standard Raspberry Pi camera, is particularly sensitive to these effects. This is great for NIR imaging, but it also means we need to be extra mindful of white balance.

Imagine trying to bake a cake with a recipe designed for a completely different oven. You might end up with something edible, but it's unlikely to be the masterpiece you envisioned. Similarly, applying AWB algorithms designed for visible light to NIR images can lead to unpredictable and often undesirable results. We need to understand how to tame this beast and achieve accurate colors in our NIR images.

Diving into the Raspberry Pi Camera Settings

Okay, so we know AWB can be a bit of a troublemaker in the NIR world. But don't fret! The Raspberry Pi camera interface provides a bunch of settings that we can tweak to get things under control. Let's explore some key settings and how they affect white balance:

• awb_mode: This is your main control switch for AWB. It dictates how the camera handles white balance. Common options include:
  • auto: The default mode, where the camera automatically adjusts white balance. This is the mode that often causes issues with NIR lighting.
  • sun: Sets the white balance for sunny outdoor conditions.
  • cloud: Sets the white balance for cloudy outdoor conditions.
  • shade: Sets the white balance for shady outdoor conditions.
  • tungsten: Sets the white balance for incandescent lighting.
  • fluorescent: Sets the white balance for fluorescent lighting.
  • off: Disables AWB completely. This is often the starting point for manual white balance adjustments.
• awb_gains: When AWB is enabled, this setting shows the gains applied to the red and blue channels. These gains are multipliers that the camera uses to adjust the intensity of each color channel. Higher gains mean more of that color is being added to the image.
• --redgain and --bluegain: When AWB is turned off, these settings allow you to manually set the red and blue gains. This gives you fine-grained control over the white balance, allowing you to dial in the perfect color balance for your specific lighting conditions.

Think of these settings as the knobs and dials on a professional camera. By understanding how they work, you can move beyond automatic settings and become a master of white balance in your Raspberry Pi projects. It might seem daunting at first, but with a bit of experimentation, you'll be surprised at how much control you have.

The NIR Challenge: Why Manual White Balance is Key

So, why is manual white balance so important when working with NIR light? As we discussed earlier, AWB algorithms are designed for the visible spectrum. They rely on assumptions about how different colors should appear under typical lighting conditions. NIR light throws these assumptions out the window.

Imagine trying to describe the taste of a new fruit to someone who's never tasted anything similar. You might use analogies and comparisons, but ultimately, they need to taste it themselves to truly understand. Similarly, the AWB algorithm is trying to
